      Monitor Ports and USB-C - A Comparison of Display Connections - USB-CIs it possible for a single connector to become the ult

imate solution and universal interface? With the introduction of the

Universal Serial Bus – C (USB-C) port, this seems to be the case.

      The USB-C is a 24-pin USB connector systemthat was developed by the USB Implementors Forum in 2014. Since then it becamethe industry standard connector to transmit data and power. It may be quitecompact, but it is incredibly powerful, boasting an array of highly advancedfeatures.

The USB-C is known as the all-in-oneconnector. It is a one-cable solution with the ability to transmit power,audio, and video across a single cable from one mighty port.

Similar in size to the USB Micro-B port, itssmaller dimensions and compatibility have made it the go-to choice forsmartphones.

The USB-C delivers more speed than itspredecessors – it’s as much as twice as fast as the USB 3.0 port. Delivering upto 100 watts of power, the USB-C is also far more powerful than older versionsof the USB. For instance, the USB 2.0 could transfer just 2.5 watts of power.

Simply put, it can power smaller devices likeyour smartphone, and larger devices, such as computers and laptops, whichgenerally require 60 watts of power to charge fully. Plus, it’s bi-directional,capable of transmitting as well as receiving power.

And with this connector, enjoy itsreversible orientation. This feature promotes ease of use and   eliminates theneed for multiple ports and cables. It also lets you easily connect the cableinto the connector correctly the first time – no more struggling to find thecorrect orientation.

Monitor Ports and USB-C - A Comparison of Display Connections - DisplayPortDisplayPort (DP) is a digital displayinterface primarily used to transmit video signals to a display unit, such as acomputer monitor. DisplayPort (DP) also support audio and USB signals.Featuring a reversible orientation, the port is highly efficient and capable oftransmitting a great deal of power (up to 100 watts) over a single cable.

DisplayPort was developed to replace VGA,DVI, and FPD-link. With the use of adapters, it also easily connects to otherinterfaces such as VGA, DVI, and HDMI.

Supporting both audio and video signaltransmissions, you can quickly get more done than ever before using onepowerful monitor. Flexible connectivity options make it possible.

Monitor Ports and USB-C - A Comparison ofDisplay Connections - mini DisplayPortA compact, stripped-down version of thepopular DisplayPort, the Mini DisplayPort (MiniDP, or MDP), is a digitalaudio-visual interface that was developed by Apple in October 2008. Describedas “the small port that makes a big difference,” this mini version of theDisplayPort was significantly smaller than its competing predecessors. It’seven smaller than the mini DVI or USB port. This advanced, compact, andversatile port was designed to be the ultimate, universal solution.

It’s replacing connectors that requiredmultiple, cumbersome screws, with a purely digital and very efficientconnection to external displays.

Monitor Ports and USB-C - A Comparison of Display Connections - HDMIOne frequently used port is the High DefinitionMultimedia Interface (HDMI). This digital interface supports both audio andvisual signals. It’s one of the most common go-to-ports for transferringhigh-definition video and audio between devices through a single cable. It is agood option for connecting an HD output to an HD display without affectinghigh-resolution images and videos.

Capable of carrying signals with the use ofinexpensive cables, and very user-friendly, HDMI has been a popular choiceamong interface connectors. It is now the standard for plugging a computer intoa TV monitor.

HDMI ports have their drawbacks, however, whichmakes other options a better choice at times. The main limitation of the HDMIcable is the distance in which its transmissions can travel (about 15 meters or 50 feet is considered the upper limit). Likewise, they are quite bulky. Astechnology has advanced, smaller versions of HDMI cables, usually called Microor Mini, were invented to accommodate our mobile devices and tablets, but thestandard size is pretty big as far as modern cables go.

Monitor Ports and USB-C - A Comparison ofDisplay Connections - DVIThe Digital Visual Interface, or DVI for short, is avideo display interface that was designed as the standard connector to transmitvideo signals to display devices.

Capable of carrying signals at resolutionsas high as 2560 x 1600, it helped maximize the digital quality of flatscreenLCD monitors and modern video graphics cards. It has been a top choice forHDTVs and other high-end video displays for TV, movies, and DVDs, while alsosupporting both computer monitors and projectors. In recent years, DVI hasbecome the standard digital interface for the computer market.

Monitor Ports and USB-C - A Comparison of Display Connections - VGAOne of the oldest ports is the Video Graphics Array(VGA). Launched in 1987 by IBM, this monitor port has been the standardconnector for video cards, computer monitors, laptop computers, projectors, andhigh-definition television sets for decades.

        VGA ports are composed of 15 pins, with threerows of five pins, it can transmit RGBHV video signals: Red, Green, Blue, Horizontal Sync,and Vertical Sync. That said, VGA is limited tocarrying analog signals,so it produces lower quality resolutions

on screens. In recent years, it has beenused far less, being replaced by faster DVI and HDMI ports, which providehigher quality resolutions and displays.
